ELECTRIC
CONTROLLER

SUMMARY

This controller is an advanced totally electronic control device which designed to replace three-phase self-coupling transformer, can be used in the resistance and inductive load. Able to control all types of torque motors.
LJK electric torque-motor controller is the newest module. It has the advantage of smaller size, better output characteristics, higher linearity, higher precision control and no interference phenomenon.

THE SCOPE OF APPLICATION

1. Environment temperature: -25℃－+55℃
2. Relative humidity: ≤85%(20℃±5℃)
3. Stall places without significant shock and vibration
4. Voltage: three-phase AC power 380V
5. Frequency: 50～60HZ

CHARACTERISTIC

Electric torque-motor controller has the advantages of small size, light weight, high efficiency, small heat, saving energy (measured by the average energy saving on more than 17%), long life, easy installation and maintenance.
Compared with three-phase self-coupling transformer, this controller’s starting performance is good, because of the installing with electron regulation, which non-contact erosion and the voltage regulator balanced.
